| Manufacturing Std | : BS 1873 |
| Face to Face, End to End | : ASME B16.10 |
| End Connection | : Flanged Ends to ASME B16.5, RF |
| : Butt Weld Ends to ASME B16.25 | |
| Inspection and Testing Std | : BS 6755 (Part-1) |
|
TESTING PRESSURE |
||||
|
TESTING |
HYDRAULIC |
PNEUMATIC |
||
|
|
150# |
300# |
600# |
|
|
BODY |
450 PSIG |
1125 PSIG |
2225 PSIG |
- |
|
BACK SEAT |
315 PSIG |
825 PSIG |
1600 PSIG |
- |
|
SEAT |
315 PSIG |
825 PSIG |
1640 PSIG |
80 PSIG |
